SISTEMI | SEWACLEAN®

Category:
Waste water treatment plant – tertiary treatment.

Description:
SewaClear® is designed to reclaim secondary effluent and industrial wastewater to meet the environmental regulations of wastewater disposal. SewaClear® allows wastewater reuse in many applications. SewaClear® is reliable and effective for removal of organic and inorganic contaminants for a broad range of municipal and industrial wastewater applications.

Raw water:

Secondary effluent – municipal / industrial waste water
BOD < 20, TSS <30

Flow rates:

20 – 20,000 m3/day

Technical specification and main components:

Primary Separation – ODIS strainer & Hydro Cyclone
Primary filtration – ODISMATIC self cleaning screen filter
Coagulation
Main filtration – ODIS multimedia filters
Disinfection
System is fully automatic

Treated water guaranteed:

BOD < 5, TSS < 5, Turbidity < 5 NTU.

Advantages:

Economical - Each system is designed specifically under consideration of customer needs and budget, with low operational costs.

Modular – system size and flow can be increased at any time simply by adding more elements (container, skid or filters).

Recovery rate – 97%. Short cleaning cycles minimize downstream flow interruptions

Automatic – Each system is fully automatic and all operating modes controlled by Programmable Logic Controller (PLC).

Easy to operate – SewaClear® is robust, reliable, weather-proof, user friendly system designed to be operated in remote areas where skilled operators, technicians, and spare parts are not readily available.

Plug n' Play – Each system is assembled and tested in the factory prior to shipment. SewaClear® models C & S are ready to operate as they leave the factory and no further on-site assembly are needed.

Applications:

Return wastewater to nature without pollution.
Small to medium size municipalities.
New building projects.
Hotels and resorts.
Industrial factories.
Landscape Irrigation — of parks, golf courses, baseball/soccer/football fields, public gardens and residential lawns.
Agricultural Irrigation.
Industrial Use — cooling towers, wash-down, and process water.
Fire Fighting — water for fire trucks, storage tanks, hydrants and sprinkler.
Decorative Fountains and Lagoons.

Optional items:

Scour air backwash: for water saving by reducing backwash cycles.
UV system for further disinfection.
And more: Independent power source (generator, solar), remote cotrol, alarms by SMS, water quality on-line controllers (PH, Chlorine, Turbidity, etc.), on-site mobile laboratory, water tanks, on-site chlorine generator, chemicals (disinfectants, coagulants etc.).
Can be combined with other Odis systems for complete water treatment package.
